New

Gatling 2.4 MK II

249.99$

  • CAD: 344.48$

This new version of the Gatling 2.4 make it much smaller and more rugged.

Description

This new version of the Gatling 2.4 make it much smaller and more rugged. Four X-air antennas perfectly matched together in unison, their cumulative gain forming a beam of over 15dBic. It easily accommodate a portable ground station or tracker. Available in either RHCP or LHCP polarization.



Features

  • Very small size relative to gain.
  • Excellent axial ratio and efficiency
  • 1/4-20 mounting thread on on the back



Specs:

  • Gain: 15.5dBic
  • Polarization: RHCP or LHCP
  • Bandwidth: 2.3-2.7GHz
  • SWR: <=1.5:1
  • Weight: xxxg
  • Dimensions: 180x180x24mm
  • Connector: SMA



*Coverage where reception is at least equivalent to an omni.
**Coverage where at least 70% of the max range is obtained.

Additional information

Weight 0.350 kg
Dimensions 26 x 26 x 7cm
Polarization

RHCP, LHCP
