SINGULARITY 2.4 V2 (OLD VERSION)

Description

The next iteration of our popular singularity antenna, smaller, more rugged and more uniform pattern.

Specs:

• Gain: 1.9dBic
• Polarization: RHCP or LHCP
• Cross-Polar Rejection: -15 to -30dB, (2.2%)
• Bandwidth: 2.4GHz-2.46GHz
• Radiation Efficiency: 99%
• SWR: <=1.5:1
• Weight: 9.45g
• Dimensions(head): 23.3mm dia. X 16.0mm height.
• Length: 96mm
• Cable: RG402/RG316/RG178 coax.
• Connector: SMA/U.FL/MMCX

US. Pat. 10,804,618
