SNIPER II 5.8 (Cosmetics Defects)

$29.99 (USD)

  • CAD: 40.58$

The new SNIPER 5.8 is our latest redesign of the sniper antenna.

Description

The new SNIPER 5.8 is our latest redesign of the sniper antenna. Almost 1/4 of the size of the original, it put an end to the only downside of this type of antenna: their size. High gain and high axial ratio make it perfect for far off venture with or without base station.

Specs

  • Frequency: 5.3-6.5GHz
  • Gain: 13.5 dBic
  • Polarization: RHCP or LHCP
  • Radiation efficiency : 98%
  • Beam-width*: 80deg
  • Beam-width @-3dB**: 45deg.
  • Connector: SMA male
  • Dimension: 52mm x 52mm x 37mm
  • Weight: 15.5g

*Coverage where reception is at least equivalent to an omni.
**Coverage where at least 70% of the max range is obtained.

Includes:

  • 1x SNIPER 5.8 antenna
  • 1x 45deg SMA adapter

Additional information

Weight 0.24 kg
Dimensions 15 x 8 x 3cm
Polarization

LHCP, RHCP
