X²-AIR 2.4 MK II

$119.99 (USD)

  • CAD: 165.59$

Following on the latest improvement of the X-AIR 2.4 MK II, this shrunk down X²-AIR is nothing less than the original beside its size.

Description

Following on the latest improvement of the X-AIR 2.4 MK II, this shrunk down X²-AIR is nothing less than the original beside its size. Bringing the high gain and wide horizontal beam in a new compact and light package.

Specs

  • Frequencies: 2.3-2.7GHz
  • Gain: 12.5 to 13 dBic
  • Beam-width Horizontal*: 150deg
  • Beam-width Vertical*: 62deg
  • Hor. beam @-3dB**: 74deg.
  • Vert. beam @-3dB**: 34deg.
  • Connector: SMA
  • Dimensions: 179.5mm x 83.5mm x 25mm l

*Coverage where reception is at least equivalent to an omni.
**Coverage where at least 70% of the max range is obtained.

Additional information

Weight 0.276 kg
Dimensions 18 x 9 x 3cm
Polarization

LHCP, RHCP
